CGT型鈦礦專用磁選機 Titanium  Special Separator

一、簡介

I. Profile

CGT系列雙滾筒稀土永磁鈦礦專用磁選機,磁源采用高性能永久磁性材料稀土釹鐵硼經組合聚磁而成。該機與普通常用的PC系列電磁盤式磁選機相比：具有機型輕便、維護操作簡單、性能穩定、耗能低、處理量大、磁選分離界限清楚等特點。

With CGT double-drum rare-earth permanent magnet titanium special  separator, the magnetic source is made of rare earth NdFeB，high-performance permanent magnetic material,  after magnet collection. Compared with common PC disc-type magnetic separators,  this type of separators have characteristics such as light body, easy operation  and maintenance, stable performance, low energy consumption, large handling  capacity, clear dividing line of magnetic separation.

二、用途

II. Application

該機主要用于鈦礦精選提純處理，也可用于其它中、弱磁性礦物的磁選分離。

This kind of separator is mainly used for concentration and  refinement of titanium ores as well as magnetic separation of other ores with  medium and weak magnetism.

三、技術參數

III. Technical  Parameter

注：除鐵滾筒直徑Ф250mm，長度與對應的Ф380鈦礦磁選滾筒一致，磁感應強度80-120mT。

Note: The diameter of deironing drum is 250mm. Its length is consistent with that of  corresponding titanium ore magnetic separation drum with the diameter of 380mm. Its magnetic induction density is  80 – 120mT.

四、機械結構與工作原理

IV. Structure  and Working Principle

該機主要由給料，電磁無級調速傳動裝置(或變頻無級調速傳動裝置)，弱磁除鐵滾筒，強磁鈦礦磁選滾筒，分礦板，鈦精礦出料斗，中礦、尾礦出料斗等部份組成。

This kind of machine is mainly composed of feeding device,  electromagnetic stepless speed regulation transmission device (or frequency  conversion stepless speed regulation transmission device), weak magnetic  deironing drum, strong magnetic titanium ore magnetic separation drum, ore  separation plate, titanium concentrate discharge hopper, middling and tailings  discharge hopper.

待選鈦礦從料斗經過弱磁除鐵滾筒首先除去鈦礦中的強磁性礦物（Fe3o4），然后經過強磁鈦礦磁選滾筒,因鈦礦帶磁性受滾筒內磁力的作用與非磁性礦物受滾筒旋轉離心力的不同作用，而落下不同的軌跡再通過分礦板的綜合調節，從而達到****的分選效果。

The titanium ores to be selected first remove the strong magnetic  ore (Fe3o4) in the titanium ores when passing from the hopper through the weak  magnetic deironing drum. Then they pass the magnetic separation drum of strong  magnetic titanium ore. Since the magnetic titanium ores is under the action of  magnetic force in the drum and non-magnetic mineralsl are under the action of  rotating centrifugal force of drum, different tracks are left. Then coupled  with combined regulation of ore separating plate, best ore separation effects  can be achieved.
