回轉烘干機 Rotary Dryer
回轉烘干機廣泛運用于建材、冶金化工、水泥工業烘干礦渣石灰石、煤粉、礦渣、粘土等物料。該機主要由回轉體、揚料板、傳動裝置、支撐裝置及密封圈等部件組成。
Rotary dryers are widely used in building material, metallurgical chemical, and cement industries to dry materials such as limestone, coal powder, slag, and clay. They are mainly composed of revolving bodies, raising material board, transmission device, supporting device, seal ring, etc.
技術參數
| 規格 | 筒體 | 生產能力 | 流向 | 電動機功率 | 重量 | |||
| 內徑 | 長度 | 傾角 | 轉速 | |||||
| mm | mm | (0) | r/min | t/h | kw | t | ||
| ф1.5×14 | 1500 | 14000 | 2.5 | 4.28 | 3-4 | 順流 | 15 | 21.0 |
| ф1.8×15 | 1800 | 15000 | 2.5 | 5 | 5-7 | 18.5 | 27.0 | |
| ф1.5×18 | 1800 | 18000 | 2.5 | 5 | 5-7 | 18.5 | 30.0 | |
| ф1.5×20 | 1800 | 20000 | 2.5 | 5 | 5-8 | 18.5 | 31.0 | |
| ф2.0×20 | 2000 | 20000 | 2.5 | 3.38 | 7-10 | 22 | 43.0 | |
| ф2.2×22 | 2200 | 22000 | 2.5 | 2.8 | 8-14 | 30 | 50.0 | |
| ф2.2×24 | 2200 | 24000 | 2.5 | 2.8 | 8-14 | 37 | 52.0 | |
| ф2.4×24 | 2400 | 24000 | 2.5 | 2.82 | 12-16 | 45 | 70.0 | |
| ф2.6×26 | 2600 | 26000 | 2.5 | 2.58 | 14-18 | 55 | 84.0 | |
| ф2.8×28 | 2800 | 28000 | 2.0 | 2.55 | 18-20 | 75 | 100.0 | |
| ф3.0×28 | 3000 | 28000 | 2.8 | 2.69 | 20-22 | 100 | 130.0 | |
